Industrial Shelf From Live Edge Slab

I’ve always liked the industrial look. A lot of it is because I like to salvage materials or repurpose them for other projects. These days with reclaimed wood and an interest in black pipe, you see a lot of influence in other areas. I wanted to make a simple industrial shelf using a live edge slab.

Industrial Shelf Made From A Live Edge Slab

Materials Needed:

  • Live edge slab of the desired size
  • Black pipe fixtures for hanging

Tools needed:

  • Chisel set
  • Stud finder
  • Hammer
  • Thick angled paint scraper
  • Saw (circular or table)
  • Sander
  • Power Drill with various circular bits (optional)
  • File and Needle (might not need)
  • Stain
  • Sealer
  • Epoxy (might not need)
STANLEY Chisel Set, 150 Series, Short Blade, Wood, 3-Piece (16-150)
  • Mpn: 16-150
  • Country of manufacture: China
  • Manufacturer: Stanley

Step 1: Get the material

Get the material | Industrial Shelf From Live Edge Slab
I went down to my local sawmill/lumber yard to see what kind of live edge wood they had. A live edge is one that still has the bark or the natural edge. I always look in the discount area first because if you know what you are doing, you can find some really good deals. If you notice on the slab I picked up, there are some discolorations on the left side. I figured I could either chop it off, sand it down or stain over it, so I got this one at a good price.

Step 2: Remove the bark

Remove the bark | Industrial Shelf From Live Edge Slab
Some things I like with bark on them and some things I don’t. With the industrial look, I didn’t want it to look too rustic. I wanted clean lines and texture. To remove the bark, if you don’t have a drawknife for removing the bark, which I don’t, use a combination of chisels and paint scrapers.

First off, I started with my set of dull chisels. I didn’t want to use the sharp ones as it can go too deeply in and hurt the edge. If you notice on the bottom right, you can see where a chunk of the wood accidentally got chipped out. As I was removing the bark, I started revealing the true wood edge and noticed that there were a lot of wormholes/tunnels/markings. I was happy as that would give the edge some cool design elements. Therefore, I needed to be careful to leave as much of that as possible while removing the bark.

Stud Finders Multi Function Wall finder Stud Finder with Sound Warning for AC Wire, Metal, Wall Studs, Wood
  • Multi-mode Detection: Detects metal studs up to 3/2 in(38mm), metal rebar or pipe up to 3 in(76mm) while AC live wire up to 3 in(76mm)
  • Multi-Scanner Stud Finder LCD Display Multi Scanning Multi Function Stud Sensor Detector with Sound Warning for AC Wire, Metal, Wall Studs, Wood.
  • LCD Backlit Display and Audible Indication: Illuminated graphical LCD and sound signal indicate mode, detection strength and more
  • Functionality: Quickly locates edges and center of metal studs, pipes, rebars, joists behind walls, floors and ceilings, also indicates the presence of live AC wire

Remove the bark | Industrial Shelf From Live Edge Slab
As I got closer to the wood edge, I would use a combination of my sharp chisels and a thick, angled paint scraper.

Step 3: Clear out the worm debris

Clear out the worm debris | Industrial Shelf From Live Edge Slab
When the worms bore through the wood, they ingest the wood and then leave behind the waste which is like a fine sawdust. You want to remove it for a variety of reasons. Since it is a different material, it will stain a different color. As the wood ages, pieces may fall out of it, taking with it the stain.

Also, you want to highlight the 3D aspect of the worm tracks. This was tedious, but it makes the finished product that much better. For the larger tracks, I used the edge of a file, but you could use any thin, hard objects. Be careful about using anything sharp as you can very easily score the wood and as this is the side you want to feature, you want to preserve it as best you can.

Clear out the worm debris | Industrial Shelf From Live Edge Slab
For the smaller tracks and holes, I used a needle. Again, it got a little annoying, but it will pay off in the end.
BLACK+DECKER MOUSE 1.2 Amp Electric Detail Sander (BDEMS600)
  • COMPACT DESIGN – Allows access to cramped corners and tight spaces.
  • POWERFUL MOTOR – 1.2 Amp motor supplies 16,000 orbits per minute for fast and thorough material removal.
  • DETAIL FINGER ATTACHMENT – Interchangeable attachment allows access to hard-to-reach spots.
  • DUST COLLECTION CANISTER – High-performance system with micro-filtration keeps your worksurface clean with less sawdust and debris.
  • 3-POSITION GRIP – For added versatility and control. POWERFUL MOTOR – 1.2 Amp motor supplies 16, orbits per minute for fast and thorough material removal.

Step 4: Remove some material to bring the weight down (optional)

Remove some material to bring the weight down (optional) | Industrial Shelf From Live Edge Slab
I used a combination of sizes of drill bits, starting with the largest and working my way down.

Good wood is heavy! First off, I cut my slab in half as I wanted a smaller shelf. Even then, the piece was around 30 – 35 lbs. I wanted to make it even lighter so that there wouldn’t be as much strain on the fixtures when I hung it.

Remove some material to bring the weight down (optional) | Industrial Shelf From Live Edge Slab
I made a guide for my drill press to make it easier for myself. You can just as easily use a power drill.

Remove some material to bring the weight down (optional) | Industrial Shelf From Live Edge Slab
In the picture above, I wanted to show the progression of the industrial shelf from right to left, of using the bits. Eventually, they all look like the hole on the left. After that was all done, I used my chisels to knock out any material left. I was able to get about 3-4 inches of wood removed which made it almost 10 lbs lighter!

Step 5: Sand it down and prep it for staining

Sand it down and prep it for staining | Industrial Shelf From Live Edge Slab
Like any project, you want to start with coarser grit and work your way to finer. I started with a 150 grit, my usual standard go-to grit for starting the sanding process. Then I worked it down with a 220 grit. On the surfaces, I used an orbital sander but for the worm face, I did it by hand so I could work around and preserve the wormy texture. All those holes you see I had to clean out with that little needle.

1/2 pt Minwax 22761 Classic Gray 271 Wood Finish Oil-Based Wood Stain
  • RICH EVEN COLOR – Minwax Wood Finish is a deep penetrating, oil-based wood stain that provides beautiful color and enhances the natural wood grain in one coat. It’s perfect for interior staining projects such as wood furniture, cabinets, doors and more.
  • QUICK DRYING – Staining interior wood has never been quicker. The special formula allows it to deeply penetrate wood pores within 5 minutes of application, resists lapping, and dries in two hours, making all your wood projects quick, beautiful and easy.
  • EASY TO APPLY – Use a clean cloth or wood stain brush to apply this wood stain in the direction of the grain. Wait 5-15 minutes and wipe away excess stain. The longer you wait, the darker/richer the color. Reapply coats for deeper color.
  • CLASSIC GRAY WOOD STAIN – This gray wood stain provides a beautiful, rich gray color. On trend and with a modern look, this light gray stain looks great on a wide variety of projects.
  • A BRAND YOU CAN TRUST – Minwax is America’s leading brand of wood finishing and wood care projects. Since 1904, we have been inspiring consumers to Keep on Finishing. We offer consumers a complete line of products to meet every wood finishing need.

Sand it down and prep it for staining | Industrial Shelf From Live Edge Slab
All the worm debris cleared out, sanded down and your industrial shelf is ready for staining.

Step 6: Stain and seal it

Stain and seal it | Industrial Shelf From Live Edge Slab
Since I knew I was going to use black pipes, I wanted the stain to be on the darker side. I picked a walnut stain and applied the stain with a rag. I did three coats over the course of a couple of days. Staining also helped me locate any other worm debris that I didn’t catch, as it would be a different color. After all the staining, I wanted to make sure that I protected it. An industrial look is not polished or shiny so I didn’t want any sort of gloss on the wood.

Stain and seal it | Industrial Shelf From Live Edge Slab
I chose a matte polyurethane so that I could protect it but it wouldn’t lose the look. Again, I did three coats over the course of a couple of days. You can see the details of the worm tracks really showing up with the stain on the industrial shelf.

Step 7: Choose and hang the hardware

Choose and hang the hardware | Industrial Shelf From Live Edge Slab
The industrial shelf was 24” long and standard studs on walls are about 18” apart. I wanted the fixtures attached at the ends, so I knew I needed to come in towards the center on both sides. I spend a good 30 minutes sitting on the floor of Home Depot with my shelf, playing around with all the various pieces, angles, sizes, and thickness. I decided on ¾” pipes. On the bottom attachment, I used a T-attachment with one open side in case I decide to build a shelf below it. That way I can connect all the fixtures for a continuous flow.

I found the studs by using a stud finder and drilling small pilot holes to make sure. This shelf is heavy, so it definitely needs to be into the studs and not just a wall anchor. First I attached just the flanges to the wall and then put together the rest of the fixtures.

Waterlox 5284qt TB5284 Stain, 32 Fl Oz
  • DURABLE WATERPROOFING: Penetrates and waterproofs when used as a finishing system in multiple coats on its own or in conjunction with Waterlox Original Satin Finish or Waterlox Original High Gloss Finish.
  • MEDIUM SHEEN: Produces a medium sheen appearance (75° gloss level when finished; fades to a 50-55° gloss level in 3-6 months)
  • LONG-LASTING: Forms a protective yet elastic finish against common household spills, moisture and foot traffic
  • VERSITLE: Our most versatile product. Many customers use only this product for all coats of finish
  • TIME-TESTED: Our oldest and truly “original” product, since 1910

Step 8: Attach the shelf

Attach the shelf | Industrial Shelf From Live Edge Slab
First I held up the shelf to where it would be fastened to the pipe flanges. I used a sharpie marker to mark where the four holes of each flange were so that I could drill pilot holes for the screws. I knew it would be difficult to attach the shelf in place, so I wanted to make sure it was as easy as it could be. Using a bit just a little smaller than my screws, I drilled all eight pilot holes. Then I put the shelf back up and attached it to the pipe fixtures.

Step 9: Decorate!

Decorate! | Industrial Shelf From Live Edge Slab
What went wrong:
Removing the bark was difficult as I was trying to find the best way of doing it. I cut too deeply a couple of times, removing more of the wood and worm tracks than I wanted. Also, be careful with the chisels while building your industrial shelf! They are sharp!

Decorate! | Industrial Shelf From Live Edge Slab
In between the staining and the sealing, some water got onto the shelf and created some minor stains. Nothing big, but I should have put something over it to protect it.

Despite tightening everything as much as I could beforehand, the angles of the bottom fixture meant that all the pieces weren’t tightened as much as they should be. This caused the shelf to push down on the right side and the fixtures would twist. To stop it, I put an epoxy on all the threaded joints to keep them in place.

J-B Weld 8265S Original Cold-Weld Steel Reinforced Epoxy - 2 oz.
  • J-B WELD ORIGINAL: The Original Cold Weld two-part epoxy system that was designed as an alternative to torch welding. J-B Weld Original provides strong, lasting repairs to multiple surfaces and creates a bond stronger than steel. Perfect for DIY household, automotive, marine, craft repair and much more.
  • CURE AND SET TIME: After mixing the tubes at a 1:1 ratio, it takes 4-6 hours to set and 15-24 hours to cure. Once cured, J-B Weld Original can be tapped, filled, sanded, molded and drilled. J-B Weld Original’s set and cure color is dark grey.
  • VERSATILE & DEPENDABLE: J-B Weld Original is steel reinforced, has a tensile strength of 5020 PSI and can withstand temperatures up to 550 degrees Fahrenheit (287 degrees Celsius). When fully cured, J-B Weld Original is waterproof and resistant to petroleum, chemical and acid.
  • SURFACE APPLICATIONS: Metal, Plastic & PVC, Wood, Concrete, Ceramic & Tile and Fiberglass.
  • DO IT YOURSELF: Big or small, you can DIY it with J-B Weld. Our heavy duty epoxy and adhesives repair & restore it right the first time. J-B Weld delivers superior performance, quality, and results for the World’s Strongest Bond.

Here’s a great video by Mr. Fix It on a DIY industrial shelf:

What do you think about this article on a DIY industrial shelf using a live edge slab? Please let us know in the comments section below.
