DIY Jewelry Making | Byzantine Chain Bracelet

DIY Jewelry Making Project | Handmade Byzantine Chain Bracelet

DIY Jewelry Making Project | Handmade Byzantine Chain Bracelet

If you want to learn how to make jewelry, the Byzantine Chainmaille Weave Bracelet is a wonderful place to start. Also sometimes called a “Birdcage Bracelet,” this Byzantine Chainmaille Weave is far easier to make than it looks, and is a style that can be incorporated into necklaces, earrings, and all other manner of jewelry projects.

We are making a two-color Byzantine Chainmaille Weave Bracelet for this tutorial, but you can obviously simplify this into one color, or make it much more detailed with three, four, or even 400+ colors if you've got the supplies. The reason we are doing it with two colors is so that it is easier to see how the rings interconnect. The reason we are not doing it with 400 colors is because we don't want to go blind staring at rings all day.

DIY Jewelry Making | Byzantine Chainmaille Weave Bracelet

This is a companion video to go along with this tutorial. It shows the steps of chain weaving from multiple angles, and will help you if you get confused on your first couple attempts.

Supplies needed to make your Byzantine Chainmaille Weave Bracelet

  • 3 yrd coil of 16 gauge Silver jewelry wire (made into about 60 jump rings, see below)
  • 3 yrd coil of 16 gauge Gold Jewelry Wire (made into about 60 jump rings, see below)
  • ALTERNATIVELY, you can just buy pre-made jump rings, but that's not how we roll at DIY Projects.
  • Magnetic Jewelry Clasp
  • Round Nose Pliers*
  • Flat Nose Pliers*
  • Wire Cutters*

*Pliers are optional if you have pre-made jump rings from the store, though you will want jewelry tools such as these if you plan on making jewelry regularly. Otherwise your fingers are going to hate you.

2 1 Byzantine Bracelet003

Step 1: Lay out your jump rings

The first step is to get your jump rings in order. Jump rings are the little rings that serve as the connecting “glue” for all manner of jewelry projects. If you've never made jump rings before, you can buy them pre-made at any craft store, or (even better) you can make your own. We have a wonderfully simple tutorial on how to build a Jump Ring Mandrel here at DIY Projects, which is an easy tool that will have you pumping out jump rings in no time.

For our two-color bracelet, we are going to need four separate piles of jump rings at the ready:

One is of our gold jump rings with the rings pulled open, one is with our gold rings with the rings closed.

Byzantine Bracelet006
We make our own DIY jump rings in big batches, then store them in containers ready to make anytime!

The third is with our silver rings pulled open, and the fourth is with the rings closed.

The number of jump rings in each pile will vary based on how big you want the bracelet to be. We went ahead and put 30 jump rings in each pile to be safe, which was more than enough. We can always use the leftover rings in future projects.

Byzantine Bracelet001

Step 2: Put gold onto silver

Take four closed silver jump rings and slip an open gold ring around them. Once it is on, close the gold ring.

Byzantine Bracelet010
Gold ring open
Byzantine Bracelet012
Gold ring closed around our four starter silver rings

Step 3: Add another gold

Now take another open gold ring and slip it around your four silver rings. This will give you four silver rings with two gold rings around them.

The reason we do this in two steps and don't just try and loop both gold rings over the silver in the same step is because it is simply easier to close the gold rings one at a time. You can certainly do them both at once if you have very dexterous fingers (and better eyesight than we do).

Byzantine Bracelet014
Slide in another gold, and close!

Step 4: Arrange your initial link

Take you initial 6-ring link you have made and organize it as shown. As you can see, it runs two silver, two gold, two silver. Man, what would we do without pictures?

Byzantine Bracelet018
2 silver / 2 gold / 2 silver

Step 5: Add a little scrap

Take a small piece of scrap wire and wrap it through the two silver rings on one end of your initial link. It doesn't matter which end you use. You do this so that, as you build your weave, you will always know which end to work on if you drop it or set it down for awhile. Trust us, it's worthwhile to do. Going forward you are going to IGNORE the scrap end and only work on the non-scrap end of the weave.

Byzantine Bracelet019

Step 6: Prepare initial link for weave

Take your 6-ring link and hold it from the sides so that the free end of weave faces up (see below). Notice how you are pinching those two bottom silver rings. Let the top two silver links rest on your fingers as shown.

Byzantine Bracelet025
This is when the good old human hand cannot beat a tool.
Byzantine Bracelet029
View from above.

Step 7: Attach a gold ring

Now see this scrap wire we slid through JUST the silver rings that are now laying on each side? The area that scrap wire passed through is where you are going to attach another open gold jump ring. Byzantine Bracelet031

So loop the new open gold ring through just the silver rings. It's a little tricky…

Byzantine Bracelet035

Step 8: Repeat

Now take another open gold jump ring and do the exact same thing. If you did it all right, your weave will now look like this:

Byzantine Bracelet047
The first half of or weave section done.

Step 9:  Second Weave Part I

To continue our two-color system, you are going to do essentially what you just did, just in reverse color order. If you flip the weave over so the scrap is hanging down (see below) you will have the two gold rings you just put on facing up. Remember, that scrap end will not be touched till much later, so don't put anything on that end.

Instead, go ahead and put a silver jump ring through those two gold rings.

Byzantine Bracelet051
Time to start part II of the section,. The two jump rings last attached need to get another set of rings on them.

Step 10:  Second Weave Part II

Then attach another silver-to-gold ring in the exact same section as you just did.

Byzantine Bracelet056

Step 11:  Second Weave Part III

And then two more gold rings to those silver rings, one at a time, same as before.

Byzantine Bracelet062

Step 12: Second Weave Part IV

Now, just like you did for the first weave, hold the chain in your fingers so the last two gold loops fall to the side.

Byzantine Bracelet069

Take another silver ring, and feed it through the golf rings via the opening in-between the two silver rings, exactly as you did when you started the weave previously.

Byzantine Bracelet074

Then add one more silver-to-gold ring in the exact same place, and it should look like this:

Byzantine Bracelet080
ONE WHOLE SECTION OF CHAIN DONE!!! Now keep going until your length of chain is where you want it….

Step 13: Repeat Until…

Continue with that sequence until the weave is long enough for your needs. For a bracelet, that worked out to about 4-1/2 inches long, but you can make yours as long as you want.

Byzantine Bracelet083
20 hours later…haha. Don't worry, as you go, the faster you get. My first try at this took me about a day and a half to figure it out. NOW I can pump out a bracelet in under 40 min.

Step 14: Add First Half Of Magnetic Clasp

Once your Byzantine Chainmaille Weave Bracelet is the desired length, you need to finish it off with a magnetic clasp. The magnetic clasp we are using only has an attachment hole big enough for ONE jump ring, so place one jump ring through the two rings that currently mark the end of your weave.

Byzantine Bracelet103

Then feed that single open weave through your magnetic clasp and close the ring.

Byzantine Bracelet105

Step 15: Add Second Half Of Magnetic Clasp

Now remove the scrap wire from the end of your first weave series. Remember that end? Wow, we haven't seen you in forever. Take off your scrap wire and thread ONE jump ring over your first two rings.

Byzantine Bracelet107
Remember that end?
Byzantine Bracelet109
Lets get a jump ring on those two jump rings at the end for our clasp to attach onto.

Thread that single jump ring through the other end of your magnetic clasp.

Byzantine Bracelet111

Voila! A beautiful two-color Byzantine Chainmaille Weave Bracelet that you can rock day or night. As we mentioned earlier, you can also make this weave even bigger for necklaces and oh so many other jewelry projects.

Byzantine Bracelet138

Hit us up with some of your own Byzantine Chain Bracelets!! We'd love to see the colors and styles you come up with.
